Can-Am 2017 X3 Stage 1-3 Tuning — Tuning Guide

Can-Am · 2017 Maverick X3

Performance Features

  • Revised intercooler fan settings.
  • Left foot braking for 2-foot operation.
  • Improved boost response.
  • Speed limits raised in high and low gear.
  • Torque limits removed in high and low gear.
  • High and low gear rev limit increased from 8300 to 9000
  • V-Max raised.
  • Improved throttle response.
  • Engine fan turns on at 185 degrees.
  • Race Start- No need to press the brake to start the engine.
Tuning Chart
  ECU Power     HP    Boost (PSI)       Wastegate     Fuel (Octane)   Recommended
  Flash Stage                            Crack                           Exhaust
                                        Pressure

(PSI)

Tuning Chart
        Stock   154        11               5              91           Stock or
                                                                       Aftermarket
      Stage 1   170        14               5              91           Stock or
                                                                       Aftermarket
      Stage 2   177        15               5              91           Stock or
                                                                       Aftermarket
      Stage 3   180        15.5             5              91           Stock or
                                                                       Aftermarket
Can-Am Maverick X3

Note: This product is exempt from the emission standards and related requirements of 40 C.F.R. § 1051 as provided by 40 C.F.R. § 1051.620, and California law [e.g., vehicle code§§ 27156 and 38391]. This product is sold only for use in connection with EPA certified, purpose-built, nonroad vehicles used solely for closed course, nonroad competition/racing and not used for any recreational purpose or on public highways or right of ways maintained by and open to the public. This product is sold only in connection with machines that do not fall under state and/or federal noise or emission standards/regulations. Purchasers who/that purchase this product represent and warrant that the product is purchased only in connection with EPA -certified, emission-regulations-exempt and noise- regulations-exempt competition/racing vehicles as interpreted under applicable state and/or federal law. Questions: Call Evolution Powersports at (715) 247-3862.
