Polaris 2020-2021 Pro XP Stage 1-5 X85 Tune Programming Information — Tuning Guide

Polaris · 2020-2021 Pro XP (RZR) · SKU 000RP0169-000RP0175

Installation

1
Remove the engine access panel between the two seats.
2
Loosen the jam nuts on the wastegate actuator rod.
3
Remove the Allen bolt securing the wastegate actuator rod to the wastegate arm.
4
Once the wastegate actuator rod is disconnected from the wastegate arm and the jam nut is loosened, turn the hiem jointed actuator end 3 full clockwise rotations (360 degrees). This will equal 6.5 LBS to the wastegate crack pressure. This will add more spring tension to the wastegate and therefore allow for more boost.
Polaris Pro XP (RZR) installation
5
Reconnect the wastegate heim joint to the wastegate arm with the Allen bolt and hardware previously removed.
6
Disconnect the OEM vacuum hose that goes to the wastegate actuator.
7
Connect the MITYVAC to the wastegate actuator and slowly pressurize the actuator.
8
Begin pumping while watching the wastegate arm. When the wastegate arm begins to move, STOP pumping and look at the PSI on the gauge. It should read.
Polaris Pro XP (RZR) installation
1
Reassemble the wastegate assembly, tighten the jam nuts.
2
Reconnect the OEM vacuum line with the given clamp.
3
All heat shields and access cover.
Polaris Pro XP (RZR) installation

Note: This product is exempt from the emission standards and related requirements of 40 C.F.R. § 1051 as provided by 40 C.F.R. § 1051.620, and California law [e.g., vehicle code§§ 27156 and 38391]. This product is sold only for use in connection with EPA certified, purpose-built, nonroad vehicles used solely for closed course, nonroad competition/racing and not used for any recreational purpose or on public highways or right of ways maintained by and open to the public. This product is sold only in connection with machines that do not fall under state and/or federal noise or emission standards/regulations. Purchasers who/that purchase this product represent and warrant that the product is purchased only in connection with EPA -certified, emission-regulations-exempt and noise-regulations-exempt competition/racing vehicles as interpreted under applicable state and/or federal law. Questions: Call Evolution Powersports at (715) 247-3862.
